BMX Bikes Radio 2021 Griffin Pro 26″ Complete Dirt Jump Bike – Matt Black

The crème de la crème of 26” bikes, the Griffin PRO is built around a super light and stiff 6061-T6 Alloy frame and is adorned with MANITOU “CIRCUS EXPERT” 100mm forks and a premium level parts package from RACE FACE and MAXXIS. A vicious unit that packs a real punch, this blacked out machine is an unstoppable partner for the rider needing a bike of no compromises.



Specifications:

• Frame : RADIO “GRIFFIN PRO” frame, 6061-T6 hydroformed & butted alloy, tapered head tube, forged yoke
• Fork : MANITOU “CIRCUS EXPERT” 100mm travel
• Handlebar : RADIO “GRIFFIN” bar, 6061-T6 alloy, 35mm
• Grips : RADIO “FREQUENCY XL” grips, flangeless, 160mm
• Stem : RACE FACE “CHESTER 35” front load stem, alloy, 40mm reach
• Headset : FSA “NO.42/ACB-A” integrated a-headset, 1-1/8″-1.5″
• Brake Lever : TEKTRO “RS-360A” front, SRAM “DB-LVL-A1” rear
• Brake : TEKTRO “ARIES” mechanical disc brake front, SRAM “DB-LVL-A1” hydraulic disc brake rear, 160mm rotor
• Crank : RACE FACE “AEFFECT” crank alloy, 170mm
• BB : RACE FACE “AEFFECT” crank alloy, 170mm
• Pedals : RADIO “SLIM” nylon/fiberglass pedals
• Chain : SALT “AM” chain, WZ1 type
• Sprocket : RACE FACE “AEFFECT” alloy sprocket 28T
• Driver : 10T cassette driver, sealed bearing
• Front Hub : RADIO “PRO-DJ” disc hub, sealed, 15mm alloy through axle, 32h
• Rear Hub : RADIO “PRO-DJ” disc hub, sealed, 3/8″s crmo axle, 32h
• Front Rim : RADIO “DB-T25” rim, double wall, sleeved
• Rear Rim : RADIO “DB-T25” rim, double wall, sleeved
• Seat : RADIO “CENTURY” pivotal seat, fat padded
• Seat Post : RADIO “PIVOTAL” seat post, alloy
• Seat Clamp: RADIO “SLIM” 31.8mm alloy clamp
• Tires : MAXXIS “DTH” tires, 2.3″ front & rear
• Weight : 11.31kg / 24.94lbs

Frame Geometry:

• Toptube: 22.8″
• Chainstays: 15″
• Headtube Angle: 70°
• Seattube Angle: 70°
• Standover Height: 10.2″
• Bottom Bracket Height: 14mm Drop

Handlebar Geometry:

• Rise 50mm
• Width 760mm
• Backsweep 8°
• Upsweep 3°
